ACTUATOR LENGTH:  9.53MM

ACTUATOR TYPE:  FLATTED (6.35MM DIA)

ANGLE OF THROW:  30°

CATEGORY:  SWITCHES

CIRCUIT PER DECK:  DP5T

CONTACT FINISH:  GOLD

CONTACT MATERIAL:  COPPER ALLOY

CONTACT TIMING:  NON-SHORTING (BBM)

CURRENT RATING:  0.4VA (AC/DC)

DEPTH BEHIND PANEL:  14.48MM

FAMILY:  ROTARY SWITCHES

FEATURES:  MODULAR BASE

INDEX STOPS:  FIXED

LEAD FREE STATUS / ROHS STATUS:  LEAD FREE / ROHS COMPLIANT

MANUFACTURER:  C&K

MANUFACTURER PART NUMBER:  A20503MNMCBE

MANUFACTURER STANDARD LEAD TIME:  9 WEEKS

MOISTURE SENSITIVITY LEVEL (MSL):  1 (UNLIMITED)

MOUNTING TYPE:  PANEL MOUNT, THROUGH HOLE

NUMBER OF DECKS:  1

NUMBER OF POLES PER DECK:  2

NUMBER OF POSITIONS:  5

PANEL CUTOUT DIMENSIONS:  CIRCULAR - 10.21MM DIA

SERIES:  A

STANDARD PACKAGE:  1

TERMINATION STYLE:  PC PIN

VOLTAGE RATING - AC:  20V

VOLTAGE RATING - DC:  20V
