CATEGORY:  DISCRETE SEMICONDUCTOR PRODUCTS

CURRENT - COLLECTOR (IC) (MAX):  141A

CURRENT - COLLECTOR PULSED (ICM):  99A

FAMILY:  TRANSISTORS - IGBTS - SINGLE

GATE CHARGE:  227NC

INPUT TYPE:  STANDARD

LEAD FREE STATUS / ROHS STATUS:  LEAD FREE / ROHS COMPLIANT

MANUFACTURER:  INFINEON TECHNOLOGIES

MANUFACTURER PART NUMBER:  AUIRGDC0250

MANUFACTURER STANDARD LEAD TIME:  25 WEEKS

MOISTURE SENSITIVITY LEVEL (MSL):  1 (UNLIMITED)

MOUNTING TYPE:  THROUGH HOLE

OPERATING TEMPERATURE:  -55°C ~ 150°C (TJ)

PACKAGE / CASE:  TO-220-3

PACKAGING:  TUBE

POWER - MAX:  543W

STANDARD PACKAGE:  50

SUPPLIER DEVICE PACKAGE:  SUPER-220? (TO-273AA)

SWITCHING ENERGY:  15MJ (OFF)

TD (ON/OFF) @ 25°C:  -/485NS

TEST CONDITION:  600V, 33A, 5 OHM, 15V

VCE(ON) (MAX) @ VGE, IC:  1.57V @ 15V, 33A

VOLTAGE - COLLECTOR EMITTER BREAKDOWN (MAX):  1200V
