CASE CONNECTION:  COLLECTOR

COLLECTOR CURRENT-MAX (IC):  5 A

COLLECTOR-EMITTER VOLTAGE-MAX:  100 V

CONFIGURATION:  DARLINGTON WITH BUILT-IN DIODE AND RESISTOR

DC CURRENT GAIN-MIN (HFE):  1000

JEDEC-95 CODE:  TO-220AB

JESD-30 CODE:  R-PSFM-T3

MANUFACTURER:  NTE ELECTRONICS INC

MANUFACTURER PART NUMBER:  NTE262

NUMBER OF ELEMENTS:  1

NUMBER OF TERMINALS:  3

PACKAGE BODY MATERIAL:  PLASTIC/EPOXY

PACKAGE DESCRIPTION:  FLANGE MOUNT, R-PSFM-T3

PACKAGE SHAPE:  RECTANGULAR

PACKAGE STYLE:  FLANGE MOUNT

PART PACKAGE CODE:  SFM

PIN COUNT:  3

POLARITY/CHANNEL TYPE:  PNP

POWER DISSIPATION AMBIENT-MAX:  65 W

POWER DISSIPATION-MAX (ABS):  65 W

QUALIFICATION STATUS:  NOT QUALIFIED

SUBCATEGORY:  OTHER TRANSISTORS

SURFACE MOUNT:  NO

TERMINAL FORM:  THROUGH-HOLE

TERMINAL POSITION:  SINGLE

TRANSISTOR APPLICATION:  SWITCHING

TRANSISTOR ELEMENT MATERIAL:  SILICON
