APPLICATIONS:  DC MOTORS, GENERAL PURPOSE

BASE PART NUMBER:  BA5984

CATEGORIES:  INTEGRATED CIRCUITS (ICS)

CURRENT - OUTPUT / CHANNEL:  1A

DETAILED DESCRIPTION:  HALF BRIDGE (10) DRIVER DC MOTORS, GENERAL PURPOSE BIPOLAR 28-HSOP

FAULT PROTECTION:  OVER TEMPERATURE, UVLO

INTERFACE:  LOGIC

LOAD TYPE:  INDUCTIVE

MANUFACTURER:  ROHM SEMICONDUCTOR

MANUFACTURER PART NUMBER:  BA5984FP-E2

MOUNTING TYPE:  SURFACE MOUNT

OPERATING TEMPERATURE:  -40°C ~ 85°C (TA)

OUTPUT CONFIGURATION:  HALF BRIDGE (10)

PACKAGE / CASE:  28-SOP (0.295", 7.50MM WIDTH) + 2 HEAT TABS

PACKAGING:  REEL

SUPPLIER DEVICE PACKAGE:  28-HSOP

TECHNOLOGY:  BIPOLAR

VOLTAGE - LOAD:  6V

VOLTAGE - SUPPLY:  4.3 V ~ 13.2 V

APPLICATIONS:  GENERAL PURPOSE
