CATEGORIES:  INTEGRATED CIRCUITS (ICS)

CURRENT - OUTPUT HIGH, LOW:  24MA, 24MA

CURRENT - QUIESCENT (MAX):  4ΜA

LEAD FREE STATUS / ROHS STATUS:  LEAD FREE / ROHS COMPLIANT

LOGIC LEVEL - HIGH:  2.1 V ~ 3.85 V

LOGIC LEVEL - LOW:  0.9 V ~ 1.65 V

LOGIC TYPE:  AND GATE

MANUFACTURER:  TEXAS INSTRUMENTS

MANUFACTURER PART NUMBER:  74AC11008N

MANUFACTURER STANDARD LEAD TIME:  6 WEEKS

MAX PROPAGATION DELAY @ V, MAX CL:  6.2NS @ 5V, 50PF

MOISTURE SENSITIVITY LEVEL (MSL):  1 (UNLIMITED)

MOUNTING TYPE:  THROUGH HOLE

NUMBER OF CIRCUITS:  4

NUMBER OF INPUTS:  2

OPERATING TEMPERATURE:  -40°C ~ 85°C

PACKAGE / CASE:  16-DIP (0.300", 7.62MM)

PACKAGING:  TUBE

SERIES:  74AC

STANDARD PACKAGE:  25

SUPPLIER DEVICE PACKAGE:  16-PDIP

VOLTAGE - SUPPLY:  3 V ~ 5.5 V
