CATEGORIES:  INTEGRATED CIRCUITS (ICS)

CIRCUIT:  10:10

CURRENT - OUTPUT HIGH, LOW:  24MA, 24MA

DELAY TIME - PROPAGATION:  7.7NS

INDEPENDENT CIRCUITS:  2

LEAD FREE STATUS / ROHS STATUS:  LEAD FREE / ROHS COMPLIANT

LOGIC TYPE:  D-TYPE TRANSPARENT LATCH

MANUFACTURER:  TEXAS INSTRUMENTS

MANUFACTURER PART NUMBER:  74ACT16841DL

MANUFACTURER STANDARD LEAD TIME:  6 WEEKS

MOISTURE SENSITIVITY LEVEL (MSL):  1 (UNLIMITED)

MOUNTING TYPE:  SURFACE MOUNT

OPERATING TEMPERATURE:  -40°C ~ 85°C

OUTPUT TYPE:  TRI-STATE

PACKAGE / CASE:  56-BSSOP (0.295", 7.50MM WIDTH)

PACKAGING:  TUBE

SERIES:  74ACT

STANDARD PACKAGE:  20

SUPPLIER DEVICE PACKAGE:  56-SSOP

VOLTAGE - SUPPLY:  4.5 V ~ 5.5 V
