CAPACITANCE:  100 NF

CAPACITOR TYPE:  ARRAY/NETWORK CAPACITOR

JESD-609 CODE:  E3

LENGTH:  3.2 MM

MANUFACTURER:  WALSIN TECHNOLOGY CORPORATION

MANUFACTURER PART NUMBER:  Y4C3B104K160CT

MOUNTING FEATURE:  SURFACE MOUNT

NEGATIVE TOLERANCE:  10 %

NETWORK TYPE:  ISOLATED C NETWORK

NUMBER OF ELEMENTS:  1

NUMBER OF FUNCTIONS:  4

NUMBER OF TERMINALS:  8

OPERATING TEMPERATURE-MAX:  125 °C

OPERATING TEMPERATURE-MIN:  -55 °C

PACKAGE CODE:  CHIP

PACKAGE DESCRIPTION:  CHIP,

PACKAGE SHAPE:  RECTANGULAR PACKAGE

PACKING METHOD:  TR, PAPER, 7 INCH

PBFREE CODE:  YES

POSITIVE TOLERANCE:  10 %

RATED (DC) VOLTAGE (URDC):  16 V

SEATED HEIGHT-MAX:  800 ΜM

SURFACE MOUNT:  YES

TEMPERATURE CHARACTERISTICS CODE:  X7R

TEMPERATURE COEFFICIENT:  15% PPM/°C

TERMINAL FINISH:  MATTE TIN OVER NICKEL

TERMINAL PITCH:  800 ΜM

TERMINAL SHAPE:  WRAPAROUND

WIDTH:  1.6 MM
