CATEGORIES:  CONNECTORS, INTERCONNECTS

COLOR:  YELLOW

CONTACT FINISH:  ELECTRO-TIN

CONTACT MATERIAL:  COPPER

EXPANDED DESCRIPTION:  YELLOW 10 STUD SPADE TERMINAL CONNECTOR CRIMP 10-12 AWG

INSULATION:  INSULATED

INSULATION DIAMETER:  0.225" (5.72MM)

LEAD FREE STATUS / ROHS STATUS:  LEAD FREE / ROHS COMPLIANT

LENGTH - OVERALL:  1.026" (26.06MM)

LENGTH - RING CENTER TO TERMINATION:  0.270" (6.86MM)

LENGTH - TERMINATION:  0.560" (14.22MM)

MANUFACTURER:  MOLEX, LLC

MANUFACTURER PART NUMBER:  0191270090

MANUFACTURER STANDARD LEAD TIME:  6 WEEKS

MATERIAL - INSULATION:  POLYAMIDE (PA), NYLON

MOISTURE SENSITIVITY LEVEL (MSL):  1 (UNLIMITED)

MOUNTING TYPE:  FREE HANGING (IN-LINE)

PACKAGING:  REEL

ROHS INFORMATION:  191270090 CERT OF COMPLIANCE

SERIES:  AVIKRIMP?

STANDARD PACKAGE:  1,000

STUD/TAB SIZE:  10 STUD

TERMINAL TYPE:  FLANGED

TERMINATION:  CRIMP

TONGUE INSIDE OPENING:  0.209" (5.31MM)

WIDTH - OUTER EDGES:  0.385" (9.78MM)

WIRE GAUGE:  10-12 AWG

ALTERNATE PARTS:  19127-0089
