BIT SIZE:  16

JESD-30 CODE:  S-XPGA-P68

JESD-609 CODE:  E0

MANUFACTURER:  AMD

MANUFACTURER PART NUMBER:  A80286-10/S

NUMBER OF TERMINALS:  68

OPERATING TEMPERATURE-MAX:  70 °C

OPERATING TEMPERATURE-MIN:  0 °C

PACKAGE BODY MATERIAL:  CERAMIC

PACKAGE CODE:  PGA

PACKAGE DESCRIPTION:  PGA, PGA68,11X11

PACKAGE EQUIVALENCE CODE:  PGA68,11X11

PACKAGE SHAPE:  SQUARE

PACKAGE STYLE:  GRID ARRAY

POWER SUPPLIES:  5 V

QUALIFICATION STATUS:  NOT QUALIFIED

SPEED:  10 MHZ

SUBCATEGORY:  MICROPROCESSORS

SUPPLY CURRENT-MAX:  600 MA

SUPPLY VOLTAGE-NOM:  5 V

SURFACE MOUNT:  NO

TECHNOLOGY:  MOS

TEMPERATURE GRADE:  COMMERCIAL

TERMINAL FINISH:  TIN/LEAD (SN/PB)

TERMINAL FORM:  PIN/PEG

TERMINAL PITCH:  2.54 MM

TERMINAL POSITION:  PERPENDICULAR

UPS/UCS/PERIPHERAL ICS TYPE:  MICROPROCESSOR, RISC
